Form Factor

8U Rack

Processor

2 x 4th Gen Intel ® Xeon ® scalable

processors, TDP 350W

GPU

NVIDIA HGX™ H100 8GPU

or

NVIDIA HGX™ H200 8GPU

Memory

Up to 32 DDR5 DIMMs and eight

memory channels for each CPU

Storage

Up to 8 NVMe SSDS (from Switch)

Up to 2 NVME/SATA SSDs (from

CPU /PCH)

1 onboard M.2 SSD (from PCH)

Expansion Slots

Up to 8 FHHL PCIe slots (from

Switch)

Up to 4 FHHL PCIe slots (from CPU)

Management

BMC：AST2600

1 RJ45 Gigabit management network

port

Front IO

2x USB, Type-A

1x PWR BTN with LED

1x UID BTN with LED

1x Status LED

1x Console PORT, Type C

1x Front VGA

Cooling

15 high-performance hot-swappable

fans with N+1 redundancy

Power Supply

Up to 8 x 54V PSU (2 are optional)

and 3+3 redundancy

2 x 12V PSU and 1+1 redundancy

Dimension

448mm(H) *352mm(W) *900mm(L)

Operation Temperature

5ºC – 35ºC
