CPU

2 x Intel ® Xeon 6700E/6500P

/6700P Processor up to 350W

GPU

8 x HGX B200 air cooling

Memory

Up to 32 DDR5 DIMM Slot,

support RDIMM up to 6400MT/s , MRDIMMs up to 8000MT/s

Storage

8 SFF NVMe slot (from switch

2 SFF SATA/Nvme slot (from CPU, SATA

need Add-in RAID card)

Option: Internal: 2 x 2280 M.2 slot (Add-in

riser card)

PCIE Extension

Front PCIe Slot: 8 x 16 FHHL/HHHL

(from switch)

Front PCIe Slot: 2 x 16 FHHL or 4 x 8 FHHL

(from CPU)

Enclosure Management

BMC:AST2600, 1 x dedicated RJ45 MGMT

port

Front IO

2 x USB3.0 Type-A Receptacle

1 x PWR BTN with 1 x PWR Indicator

1 x Status LED

1 x VGA

1 x UART Port Over TypeC

1 x UID button & LED

1 x GbE MGMT Port

Cooling

20 x 8086 FANs, N+1 Redundant

Operation Temperature

5ºC – 35ºC

PSU

2 x 185mm Redundant 2700W HVDC/

AC Input, 12V Output PSUs

8 x 185mm Redundant 3200W HVDC/

AC Input, 54V Output PSUs

Dimension

440mm(H) x 448mm(W) x 900mm(D)
